Multi-Channel Data Logger
View 1
View 2
View 3
View 4

Multi-Channel Data Logger

Starts from ₹25,000 ₹27,999
Select Options

Multi-Channel Data Logger by AIOTHUB records multiple parameters simultaneously, reducing hardware costs while delivering synchronized data, centralized monitoring, scalable expansion, precise analysis, faster decisions, and improved operational efficiency.

Single-Channel Multi-Channel
WhatsApp
SKU: AIOT-DL-MC-2025
Category: Industrial Hardware
Tags: IoT, Multi-Channel, Automation
Free Shipping
1 Year Warranty
24/7 Support

Comprehensive Industrial Monitoring

The AIoTHUB Multi-Channel Data Logger acts as a central hub for your entire sensor network. With support for multiple protocols (Modbus, MQTT, OPC-UA), it consolidates data from up to 16 sources into a single unified stream.

Wireless Connectivity

Supports Wi-Fi, 4G/LTE, and Ethernet for redundant connectivity.

Local Storage

Built-in SD card slot ensures no data loss during network outages.

Easy Config

Web-based configuration dashboard required zero coding knowledge.

Input Voltage 12V - 24V DC
Operating Temp -10°C to 65°C
Connectivity Wi-Fi (2.4GHz), Ethernet, 4G LTE (Optional)
Digital Inputs 16 Isolated Channels
Dimensions 140mm x 90mm x 35mm

Technical Specifications

Processor & Memory
CPU Quad-Core ARM Cortex-A53 @ 1.5GHz
RAM 1GB LPDDR4
Storage 8GB eMMC (Expandable via SD up to 256GB)
Communication Interfaces
Ethernet 2x 10/100/1000 Mbps RJ45 Port
Serial Ports 4x RS485 (Modbus RTU), 2x RS232
USB 2x USB 3.0 Host
Power & Environment
Power Supply 9-36V DC Wide Input
Power Consumption < 8W
Mounting DIN Rail Mountable

Frequently Asked Questions

Yes, the device comes with an optional 4G LTE module. You can insert a standard Mini-SIM card to enable cellular connectivity.

Absolutely. The device supports Modbus TCP/IP and MQTT, making it compatible with most modern SCADA and cloud platforms.

Yes, it has internal storage and supports SD cards specifically for data buffering. Once connectivity is restored, it uploads the stored data automatically.

We offer a standard 1-year warranty on hardware, which can be extended up to 3 years with our premium support package.

Rajesh Kumar Oct 12, 2025

Excellent device. We implemented this in our pharmaceutical plant and it has been running flawlessly for 3 months.
